KST DS215MG V3.0 - 2BB 7.4V 3.7kg 0.05 sec/60° Coreless Swashplate CCPM/Rudder Metal Servo For 450 480 500 class RC Helicopter
KST DS215MG V3.0 - 2BB 7.4V 3.7kg 0.05 sec/60° Coreless Swashplate CCPM/Rudder Metal Servo For 450 480 500 class RC Helicopter - Image 2
KST DS215MG V3.0 - 2BB 7.4V 3.7kg 0.05 sec/60° Coreless Swashplate CCPM/Rudder Metal Servo For 450 480 500 class RC Helicopter - Image 3
KST DS215MG V3.0 - 2BB 7.4V 3.7kg 0.05 sec/60° Coreless Swashplate CCPM/Rudder Metal Servo For 450 480 500 class RC Helicopter - Image 4
KST DS215MG V3.0 - 2BB 7.4V 3.7kg 0.05 sec/60° Coreless Swashplate CCPM/Rudder Metal Servo For 450 480 500 class RC Helicopter - Image 5
KST DS215MG V3.0 - 2BB 7.4V 3.7kg 0.05 sec/60° Coreless Swashplate CCPM/Rudder Metal Servo For 450 480 500 class RC Helicopter - Image 6

The KST DS215MG V3.0 - 2BB 7.4V 3.7kg 0.05 sec/60° Coreless Swashplate CCPM/Rudder Metal Servo For 450 480 500 class RC Helicopter is a drone product in the Drone Servos category priced at $19.99, featuring DS215MG V3.0.

,

KST DS215MG V3.0 – 2BB 7.4V 3.7kg 0.05 sec/60° Coreless Swashplate CCPM/Rudder Metal Servo For 450 480 500 class RC Helicopter - Drone Servos

$19.99

+ Free Shipping
- +

Regional payment methods

Payssion regional payment methods
SKU: N/A Categories: ,
Ask for more info

Best Use Cases

  • Used to Stainless Steel, from Aluminum.

Key Specifications

  • type: DS215MG V3.0
  • torque: 3.7kg.cm @ 7.4V; 3.1kg.cm @6V
  • speed: 0.05 (sec/60°) @7.4V; 0.06 sec/60°@ 6V
  • voltage: DC 6V to 7.4V
  • working_signal: 1520us/333HZ,800-2200us
  • motor: 12mm, corless motor
  • dimension: 27.5x23x12mm
  • weight: 20g

Compared to Alternatives

Compared to 3 alternatives in the Drone Servos category, the KST DS215MG V3.0 - 2BB 7.4V 3.7kg 0.05 sec/60° Coreless Swashplate CCPM/Rudder Metal Servo For 450 480 500 class RC Helicopter is $19.99.

Frequently Asked Questions

  • What are the key specifications of KST DS215MG V3.0 - 2BB 7.4V 3.7kg 0.05 sec/60° Coreless Swashplate CCPM/Rudder Metal Servo For 450 480 500 class RC Helicopter?
    Type: DS215MG V3.0; Torque: 3.7kg.cm @ 7.4V; 3.1kg.cm @6V; Speed: 0.05 (sec/60°) @7.4V; 0.06 sec/60°@ 6V.
  • What is KST DS215MG V3.0 - 2BB 7.4V 3.7kg 0.05 sec/60° Coreless Swashplate CCPM/Rudder Metal Servo For 450 480 500 class RC Helicopter best used for?
    Used to Stainless Steel, from Aluminum.
  • How much does KST DS215MG V3.0 - 2BB 7.4V 3.7kg 0.05 sec/60° Coreless Swashplate CCPM/Rudder Metal Servo For 450 480 500 class RC Helicopter cost in the Drone Servos category?
    KST DS215MG V3.0 - 2BB 7.4V 3.7kg 0.05 sec/60° Coreless Swashplate CCPM/Rudder Metal Servo For 450 480 500 class RC Helicopter is available at priced at $19.99 on 100drone.com.

SPECIFICATIONS

Brand Name: Feetech

Origin: Mainland China

Material: Metal

RC Parts & Accs: Servos

Size: 23x12x27.5mm

For Vehicle Type: Helicopters

Use: Vehicles & Remote Control Toys

Upgrade Parts/Accessories: Arm

Remote Control Peripherals/Devices: Servos

Tool Supplies: Sticker

Technical parameters: Value 2

Model Number: DS215MG

Four-wheel Drive Attributes: Motors

Wheelbase: Screws

KST DS215MG V3.0 2BB 7.4V 3.7kg 0.05 sec/60° Coreless Swashplate CCPM/Rudder Metal Servo For 450 480 500 class RC Helicopter servo

This is the KST DS215MG Micro Digital Servo, for Cyclic and Tail use. Looking for speed in a micro package? The KST DS215MG is lightning fast, high voltage compatible and comes in a beautiful aluminum case. Power comes via a coreless motor, running on silky smooth bearings with all metal gears. For the ultimate in speed and accuracy, turn to the DS215MG for your demanding needs.

V3.0

As time has progressed, KST has done additional development on the gear train of the 215 servo, and changed the servo gear material used to Stainless Steel, from Aluminum. This means that the metal gear train will be much more durable than previous versions, improving durability greatly.

Micro size aluminum case

Full metal gears

Dual ball bearings

HV compatible

Lightning fast

Coreless motor

Specification
Type: DS215MG V3.0
Torque: 3.7kg.cm @ 7.4V; 3.1kg.cm @6V
Speed: 0.05 (sec/60°) @7.4V; 0.06 sec/60°@ 6V
Voltage: DC 6V to 7.4V
Working signal: 1520us/333HZ,800-2200us
Motor: 12mm, corless motor
Dimension: 27.5x23x12mm
Weight: 20g

KST DS215MG V3.0, the metal gear train will be much more durable than previous versions . this means that the metalKST DS215MG V3.0 - 2BB 7.4V 3.7KST DS215MG V3.0, the KST DS215MG is lightning fast, high voltage compatible and comes in KST DS215MG V3.0, the DS215MG is the ultimate in speed and accuracy . it is available inKST DS215MG V3.0, the metal gear train will be much more durable than previous versions . this means that the metalKST DS215MG V3.0, KST DIGITALSERVO KST VJ0 DSZ15MG (6
