ToolkitRC MC8 – Smart Battery Multi-Checker Balancer Receiver Signal Tester Quick Charge Function For FPV Drone Helicopter

$56.41

+ Free Shipping
Default Title
Default Title
Clear

ToolkitRC MC8 SPECIFICATIONS

Tool Supplies: Battery

Remote Control Peripherals/Devices: Battery

RC Parts & Accs: Batteries – LiPo

Origin: Mainland China

Material: Plastic

Four-wheel Drive Attributes: Assemblage

For Vehicle Type: Airplanes

Certification: CE



Specifications

Main input port XT60 7.0V-35.0V
Balance input 0.5V-5.0V Lixx 2-8S
Signal port input <6.0V
Balance current MAX 60mA @2-8S
Balance accuracy <0.005V @ 4.2V
USB-A output [email protected] firmware upgrade
USB-C output 5.0V-12.0V @MAX 20W
USB-C protocol PD3.0 QC3.0 AFC SCP FCP

Measurement

PWM 500-2500us @20-400Hz
PPM 880-2200us*8CH @20-50Hz
SBUS 880-2200us *16CH @20-100Hz

Output

PWM 1000-2000us @20-1000Hz
PPM 880-2200us*8CH @50Hz
SBUS 880-2200us *16CH @74Hz
Item Size 68mm*50mm*15mm
Item Weight 50g
Package Size 76mm*60mm*30mm
Package Weight 100g
LCD IPS 2.0 inch 240*240 resolution
