SIYI AI Tracking Module for Drone Overview
The SIYI AI Tracking Module for Drones features 4 Tops @ INT8 computing power, recognizing and tracking humans, vehicles, and boats with 95% accuracy. It supports multi-target recognition and gimbal camera collaboration for dynamic, anti-lost tracking, including auto-zooming and centering. With an average power consumption of 8W, it operates efficiently between -10ºC and 50ºC. Its compact size (43.4 x 45.1 x 26.5 mm) and lightweight design (60 g) make it ideal for various drone models. This module is perfect for applications requiring precise object recognition and tracking, such as surveillance, search and rescue, and automated inspections.
SIYI AI Tracking Module for Drone SPECIFICATIONS
Specification | Details |
---|---|
Recognizable Object Types | Human, Vehicle (Car, Truck, Bus), Boat |
Computing Power | 4Tops @ INT8 |
Power Consumption | Average: 8 W |
Power Input | 12.6 ~ 25.2 V (3S ~ 6S) |
Video Stream Compatible Codec Format | H.264 / H.265 |
Dynamic Target Gimbal Camera Collaboration | Locking Target, Auto Zooming on Target, Auto Centering Target in Image |
Recognizing / Locking Target Accuracy | 95% |
Working Temperature | -10ºC ~ 50ºC |
Product Dimensions | 43.4 x 45.1 x 26.5 mm |
Product Weight | 60 g |
SIYI AI Tracking Module Descriptions
AI-powered drone tracking module with 4T computing power for human and vehicle multi-target recognition, gimbal camera collaboration, mini size, lightweight, and anti-lost capabilities.
SIYI’s AI Tracking Module boasts 4T computing power with up to 4 Tops INT8 processing capacity, enabling real-time AI recognition and tracking control of drones. It excels in various applications such as surveillance, agriculture, forestry, environmental monitoring, logistics, and transportation.
SIYI’s AI tracking module recognizes pedestrians, vehicles (cars, trucks, buses) and boats using AI technology, automatically monitoring multiple targets in real-time.
SIYI AI Tracking Module collaborates with gimbal cameras and optical pods for real-time target tracking and capture, highlighting subjects through zoom and focus. It also features anti-lost functionality, automatically recognizing and re-tracking targets if they momentarily leave or are blocked from view.
Compact and lightweight, this SIYI AI tracking module is specifically designed for drone applications, featuring a mini size, low power consumption, Ethernet output, HDMI video stream port, and abundant features.
Compact AI tracking module for drones, weighing 60g with dimensions of 26.5mm x 73mm, suitable for multi-target recognition and anti-lost applications.
Connect the SIYI AI Tracking Module’s standard cable to the air unit for power input, and connect the gimbal power input to the MKIS HM30 air unit via a standard cable.
SIYI AI Tracking Module for Drones: Recognizes humans and vehicles (cars, trucks, buses), boats, with 4TOPS INT8 computing power; average power consumption: 8W; compatible with H.264 and H.265 codecs; features dynamic target locking, auto-zooming, and high accuracy (95%); temperature range: -20C to 60C; dimensions: 43.4×45.1×26.5mm; weight: 60g.
