Detailed introduction
FEATURE:
— High performance digital coreless standard servo
— High-precision Taiwan-made aluminium gears with hard anodizing
— CNC aluminium middle Shel
— Dual ball bearings
SPECIFICATIONS:
Dead band: 1μs
Working frequence: 1520μs / 330hz
Motor: coreless motor
Operating Speed (4.8V): 0.105sec/60°
Operating Speed (6V): 0.083sec/60°
Stall Torque (4.8V): 8.95 kg.cm (124.29oz/in)
Stall Torque (6V): 10.68kg.cm (148.31oz/in)
Dimensions: 40.5X20.5X36.5mm/1.59X0.80X1.43in
Weight: 61 g (2.15oz)
Connector Wire Length: JR 265 mm (10.43in)
Bearing: 2BB
