HGLRC Zeus F760 F7 Flight Controller – 3-6S w/5V 9V BEC & 60A BL_32 DShot1200 4 in 1 ESC Stack For RC Racing Drone DIY Accessories

Package Included:

1x F7 Flight Controller

1x 60A BL_32 4In1 ESC

8x Anti-vibration Ball

1x bag of Screws

1x bag of Cables

1x Capacitor

1x Connector

Specification:

Brand Name: HGLRC

Model: F760 Stack

Item Name: F7 Flight Controller & 60A 4In1 ESC Flytower

Stack Weight: 32.7g

Application: compatible with 100mm-450mm Frame Kit

Forward F722 F7 OSD Flight Controller Board

MPU: MPU6000

CPU: STM32F722 RET6

Input Voltage: 3-6S Lipo

Built-in Betaflight OSD to adjust PID

Built-in LED Controller

BEC Output: 5V 3A 9V 2A

Black Box: 16M

Size: 37.3×37.3mm

Mounting Hole: 30.5×30.5mm

M3 Weight: 7.6g

UARTS: 5

UART1: Receiver ( SBUS/IBUS/DSMX/R9MM/CRSF)

UART2:

UART3: VTX

UART4: GPS

UART6: ESC Telemetry

Forward 60A BLheli_32 32bits 4in1 ESC

CPU: STM32F051

Con. Current: 60A

Burst Current: 65A (10S)

Input Voltage: 3-6S Lipo

BEC: NO

Supported Protocols: DSHOT1200/600/300/150, ONESHOT125/42

Mounting Hole: 30.5×30.5mm, M3

Size: 45x40x6.5mm

Weight: 18g

Quickly connect LEDs and one GPS module to the HGLRC Zeus F760/F7 flight controller via the socket, which has a maximum BEC (Battery Eliminator Circuit) output of 3A.

The Zeus F760 F7 Flight Controller supports boot via USB-C, featuring a forward design with a 60A BL32 motor driver, compatible with 3-6S batteries, and a 4-in-1 ESC with dimensions of 15.3mm x 45mm x 40mm.

Forward-facing camera output suitable for 100mm to 400mm frame kits. The LED indicator inside the white lines can be controlled via a dedicated button.
