Description
SPECIFICATIONS
Warning: Minors please use under the supervision of an adult
Video Capture Resolution: 1080p FHD
Video Capture Resolution: 2K QHD
Type: HELICOPTER
State of Assembly: Ready-to-Go
Remote Distance: 1500 meters
Remote Control: Yes
Recommend Age: 12+y
Power Source: Electric
Plugs Type: XT30
Package Includes: Operating Instructions
Package Includes: Original Box
Package Includes: Camera
Origin: Mainland China
Operator Skill Level: Beginner
Operator Skill Level: Expert
Operator Skill Level: Intermediate
Motor: Brushless Motor
Model Number: GEPRC Crocodile Baby 4 Analog Micro Long Range
Material: Metal
Material: Plastic
Material: Carbon Fiber
Indoor/Outdoor Use: Outdoor
Flight Time: 25-30 minutes
Features: App-Controlled
Features: FPV Capable
Features: Other
Dimensions: 4 inch
Controller Mode: MODE2
Controller Mode: MODE1
Controller Battery: not include
Control Channels: 8 Channels
Charging Voltage: 14.8V
Charging Time: 40 minutes
Camera Mount Type: Fixed Camera Mount
Brand Name: GEPRC
Aerial Photography: Yes
Summary:
The most distinguished 4 inch Micro Long Range quadcopter,With superb light-weight design frame and more than 28 Minutes flight time,GEPRC Crocodile Baby 4inch is launching right now,It was just a complete out-of-body experience. There are three versions:DJI HD VTX,Analog VTX 5.8G 600MW and 4K HD recording camera version.Pilots can choose whichever based on their likings.
Crocodile Baby 4 inch is the lightest 4-inch Micro Long Range FPV at present.The minimum takeoff weight is within 250g,which conforms to FAA rules.If you are looking for a FPV that can fly around 30 minutes,Crocodile Baby 4 inch is powerful and flexible flight.it will satisfy all your needs.
Crocodile Baby 4 inch is the preferred choice for Micro Long Range flight.The High efficiency power system,New Produced GEPRC 1404 2750kv motor and Gemfan 4024 propeller,Using the latest GEP-20A-F4 AIO flight control system, and combine with DJI HD picture transmission system,It is very stable flight and providing a feeling of “easy control” that inspires confidence, especially among novice.In the hands of a skilled pilots, the Crocodile Baby can bring extreme awesome experience as well.Extensive testing ensures that frame and system hold up in any environment,It can work well and get better flight efficiency.If equipped with GEPRC Lion VTC6 3000mAh battery,flight time is more than 28 minutes.
Crocodile Baby 4 inch independently designed GPS module, added GPS function.When signal losing or VTX out of control,It can be start the rescue mode of betaflight (in emergency,The FPV fly back to the approximate position of the base,If the signal is get again,Be sure to operate the FPV to landing manually.) ,The Rescue mode won’t landing automatically.Crocodile baby integrates GEPRC Finder. If the FPV lost and disconnects the battery power,the beeper of GEPRC Finder will making the sound constantly.
Crocodile Baby 4 inch is assembled and debugged by GEPRC TEAM,Improved performance and the flight performance of the whole FPV always superior in Micro Long Range FPV flight.
-
Brand:GEPRC
-
Model: Crocodile Baby 4″ Analog 4K
-
Frame:GEP-CB4
-
Wheelbase:174mm
-
he thickness of the top plate:1.5mm
-
The thickness of the bottom plate:2.0mm
-
The thickness of the arms plate:2.5mm
-
XT30 Connector
-
Camera: CADDX RATEL 2
-
MCU:STM32F722RET6
-
IMU:MPU6000(SPI)
-
Type-C USB interface
-
OSD:BetaFlight OSD w/ AT7456E chip
-
Integrated LC Filter
-
Power input:4S LiPo
-
VTX:STABLE F4 5.8g 600mW VTX
-
Props:Gemfan 4024
-
Antenna:GEPRC Momoda 5.8g RHCP
-
Motors:GR1404 2750KV
-
GPS:BN-228
-
Crocodile Baby 4″ HD Weight:242g (Include 4S 750mAh battery)
-
Receiver:PNP(with DJI Receiver) / Frsky XM+/ Frsky R9mm /TBS Nano RX
-
Motors:GR1404 2750KV
-
Battery:4S 650mAh – 1300mAh Lipo or 4S Lion 3000mAh
-
1x Crocodile Baby 4″ Analog Quads
-
4x Gemfan 4024 Props(pairs)
-
2x The silicone pad
-
3x L-shaped screwdriver
-
1x Antenna protection tube
-
1x Spare front arms
-
1x Spare rear arms
-
2x 12*180mm battery strap
-
1x 15*200mm battery strap
-
1x Adjustment Board of Camera
If equipped with GEPRC Lion VTC6 3000mAh Battery,flight time is more than 28 minutes.
