Tarot TL5D001 5D3 3-Axis Self-stabilizing Gimbal Camera Mount for Tarot X6 Hexcopter Fpv Canon EOS 5D Mark III PF Mode

Introduction:
The Tarot 5D3 3-Axis self-stabilizing gimbal is specifically designed to carry the Canon 5D Mark III and 5D Mark II camera and perfectly match with Tarot X6 Hexacopter. Its CNC processing with thin-walled structure gives you a stable footage and precise control even in the most difficult flight conditions.

The Tarot 5D3 is based on gimbal system with optimal algorithm. Built-in independent IMU module gives you precise and effortless control. Three working modes are supported, orientation locked, Non orientation locked and FPV. Built-in slip ring simplifies the cabling. The command stick controls gimbal rotation velocity.

Tarot 5D3 3-Axis self-stabilizing gimbal can be converted into handheld gimbal with quick release handle (the handle needs to be purchased additionally). Tarot 5D3 3-Axis self-stabilizing gimbal is your best choice.

Features:
– Working modes
Orientation-locked control
Non orientation-locked control
FPV mode
– Bulit-in independent IMU module
– Tarot gimbal special servos drive module
– AV output port
– Camera shutter control supported
– Wide range voltage input supported
– S-Bus/PPM/DSM receiver supported

Peripheral
– Supported Camera: CANON EOS 5D MARK III & 5D Mark II only
– Supported Lens Currently: CANON EF 17-40mm f/4L USM
– GCU Input Power: 3S~6S LiPo
– Control Requirement: At least four spare receiver channels
– Assistant Software System Requirement: Windows XP SP3; Windows 7; Windows 8 (32 or 64 bit)

Mechanical & Electrical Characteristics
– Working Current: 120mA (@25V) 180mA 3S-6S Li (11V-26V)
– Operating Temperature: -20°C ~ 50°C
– Weight: 1.51KG
– Dimensions: 215mm*240mm*246mm

Working Performance
– Controlled Angle Accuracy: ±0.02°
– Maximum Controlled Rotation Speed:
– Pan axis: ±200°/s
– Tilt axis: ±200°/s
-Roll aixs: ±200°/s
– Rotation:
– Pan axis control: ±360° continuous rotation
– Tilt axis control: -135°-+45°
– Roll axis control: ±48°
