PandaRC VT5804M V2 VT5804 HV MAX VTX SPECIFICATIONS
Brand Name: PandaRC
Origin: Mainland China
Material: Composite Material
Recommend Age: 14+y
RC Parts & Accs: RECEIVERS
Size: Vehicles & Remote Control Toys
For Vehicle Type: Airplanes
Use: Vehicles & Remote Control Toys
Certification: FCC
Certification: none
Upgrade Parts/Accessories: tires
Remote Control Peripherals/Devices: RECEIVERS
Tool Supplies: Assembled class
Quantity: 3
Technical parameters: Value 4
Model Number: VT5804 HV
Four-wheel Drive Attributes: Assemblage
Wheelbase: Bottom Plate
Item Type: RC Accessory
Model: VT5804HV MAX
Material: Plastic + Electronic Components
Color: As Shown in the Picture
Weight: Approx. 12g
Input Voltage Range: 7-24V
Frequency: 48CH
Output Power: 0mW/25mW/100mW/200mW/400mW/600mW Switchable
Transmission Distance: ≥0.5km 25mW, ≥1km 200mW, ≥2km 600mW
Features:
1. Output power is stable and transmission distance is far: ≥0.5km 25mW, ≥1km 200mW, ≥2km 600mW (stick antenna).
2. Switchable transmitting power, including 0mW / 25mW / 100mW / 200mW / 400mW / 600mW mode.
3. Output 48 frequency points, and have E group, F group 8 competing frequency at the same time using each other without interference.
4. Frequency lock fast, boot does not interfere with companions.
5. Comes with output power self-test function.
6. Full format video format: NTSC / PAL.
7. Wide input voltage range and low power consumption: 7V-24V, +12V/260mA 600mW.
8. Installation hole corresponds to CC3D NAZE32 F3 F4 flight control.
9. Built-in OSD to set PID, frequency , channel and FPV transmission power.
Package included:
1 * PandaRC VT5804MAX V2 VTX
1 * Connection Cable
