Package Included: Send it as your choice
Brand:Readytosky
Weight: SMA/RP-SMA:7.6g / UFL:2.9g / straight MMCX: 3.7g
Interface: SMA / RPSMA / UFL / straightMMCX
Длина:
SMA, RPSMA:61mm
MMCX :60mm
UFL :60mm
Super Mini Stubby 5.8G 5dBi Antenna
Frequency:5000-6000MHz
Gain:5dBi
Axial Ratio:0.74
Weight:6.8g
Height:Φ21*28mm
Connector: RP-SMA(inner hole) or SMA (inner needle)
Black Sheep BlackSheep 5.8G antenna RP-SMA / SMA (Long / Short version)
While other antennas rely on copycat designs the TBS Triumph takes a giant leap in 5.8 GHz antenna technology. Video Aerial Systems LLC (IBcrazy) and Team-BlackSheep have come together to re-invent how the modern 5.8 circular polarized antenna should look and perform.
In our quest for the cleanest video signal and best range possible, we have ventured way beyond the traditional bent lobes of Cloverleaf designs and invested significant time and effort in finding the best antenna designs known to man, and modifying them specifically for FPV use.
After extensive design and testing, we focused on making sure the Triumph was durable enough to take even the toughest of abuse. After many test flights and extensive feedback from our pilots, we decided to use a double-jacket heavy duty Semi-Rigid cable and tin-plated connectors. For protection we created a special foam-filled and ultrasonic welded enclosure to secure the antenna from inbound trees, or other objects 🙂
FEATURES:
Manufactured and tested to highest standards
Best in class range and signal quality
Extra compact and low weight
Ultrasonic welded and foam infused cover for ultimate crash-protection
Double-jacket semi-rigid cable for heavy impact resistance
TECHNICAL SPECIFICATIONS:
Frequency range: 5500-6000MHz
Gain: 1.26dbic
Axial Ratio: 0.74
Height:85mm, 3.3 in
Connector: RP-SMA (inner hole)
Connector: SMA (inner needle)
V2 Stubby 5dBi FPV Antenna
Frequency:5600-5900MHz
Gain:5dBi
VSWR: ≤1.5
Polarization：RHCP / LHCP
Axial Ratio:1.2
Weight:6.2g
