Tarot TL3T01 CAMERA SPECIFICATIONS
Колесная база: Винты
Модернизация деталей/аксессуаров: Адаптер
Поставки инструментов: Резка
Технические параметры: Значение 2
Размер: Как описание
Периферийные устройства/устройства дистанционного управления: Пульт дистанционного управления
Рекомендуемый возраст: 12+y,18+
Запчасти и принадлежности RC: ОСЬ
Количество: 1 шт.
Происхождение: Материковый Китай
Номер модели: Tarot TL3T01
Материал: Металл
Атрибуты полного привода: Сборка
Для типа автомобиля: Самолеты
Пакет включает:
3-axis metal gimbal 160 g x1
PTZ control module (36x25x11MM) x1
8P main controller-gimbal cable x1
5V output, the receiver and video cable x1
USB module (27x21x7MM) x1
Flight control cable x1
Manual x1
Box x1
Технические характеристики:
Designed based on T-3D gimbal
Developed for GoPro. Quick installation
Accurate control for vivid image
Each axis speed is controllable
Supports AL/PF/FPV mode.
With built-in TAROT servo driven module
Описание:
Tarot GOPRO 3D III metal three-axis head designed for GOPRO HERO 3/3 + / 4 camera customized, integrated TAROT series PTZ all high-end technology, with full CNC processed, bringing lightweight and high stability, helping to output nice image. Tarot GOPRO 3DIII metal 3-axis gimbal is with built-in TAROT servo driven module, supports AL/PF/FPV mode.
Mechanical / electronic specifications
Applicable Camera Type: GOPRO HERO 3/3 + / 4
Input Power: 3S-6S Li (11V-26V)
Operating Current: 30mA (@ 25V) / 50mA (@ 12V)
Stall Current: 350mA (@ 25V) / 700mA (@ 12V)
Attitude control accuracy: ± 0.02 degrees
Maximum controllable speed
The direction of rotation (PAN): ± 200 ° / s
Pitch direction (TILT): ± 200 ° / s
Roll direction (ROLL): ± 200 ° / s
The controllable range of rotation
The direction of rotation (PAN): ± 330 °
Pitch direction (TILT): -135 ° to + 45 °
Roll direction (ROLL): ± 48 °
S-Bus / PPM / DSM receiver supports
Working temperature: -20 ¢J ~ + 50 ¢J
Maximum dimensions (LWH): 60 mm * 75 mm * 100mm
Assistant Software Installation Requirements
Windows XP; Windows VISTA; Windows 7; Windows 8 (32 or 64 bit)
China patent number : 2014201546579
