TOPOTEK KIP20S78 Drone Camera Gimbalis a single optical gimbal camera featuring 4K star light night vision, 20x optical zoom, 3-axis stabilized PTZ, and IP output. The ground receiving end IP outputs RTSP code streams, and the ground end software supports PTZ control and zoom camera control. The PTZ uses a high-precision encoder FOC control scheme, offering high stability, small size, lightweight design, and low power consumption. The camera includes a low-light night vision capability with an 8-megapixel effective SONY STARVIS2 sensor, supporting 4K and 1080P local TF storage and wireless transmission.
Advantages
- 4K Visible Light Camera: Captures ultra-high-definition video in visible light.
- 20x Optical Zoom: Allows for detailed close-ups without losing image quality.
- Standard RTSP Stream Output: Ensures compatibility with various streaming applications.
- TF Card Storage: Provides convenient and expandable local storage.
- HD Night Vision (0.29 lx): Enhances low-light performance for clear nighttime imaging.
- 170ms Low Latency: Offers near-instantaneous feedback and control.
- 9x Digital Zoom: Adds further flexibility in framing shots.
- Image and Data Use the Same IP: Simplifies network configuration and reduces the need for additional hardware.
- 3-Axis Stabilized Gimbal: Ensures smooth and stable footage, even in dynamic conditions.
- Lightweight at 635g: Easy to integrate into various platforms without adding significant weight.
TOPOTEK KIP20S78 Drone Camera Gimbal Specifications
| Параметр | Технические характеристики |
|---|---|
| Напряжение | 3S-6S (11V-24V) |
| Мощность | Динамический 10 Вт |
| Угол поворота | -45°~+45° |
| Угол продольного наклона | -45°~+120° |
| Угол рысканья | 360° continuous rotation |
| Угол джиттера | ±0.02° |
| Угол горизонтального джиттера | ±0.03° |
| Восстановление одним кликом | Восстановление исходного положения одним щелчком мыши |
| Регулируемая скорость вращения кардана | When the PTZ rotates, it conducts speed adaptation based on the current speed mode and the multiple of visible light camera. |
| Режим управления | Support network IP control and serial port control (SBUS and PWM control are optional) |
| CMOS Size | 1/1.8 Inch 8 Mega Pixels Wide Dynamic CMOS SENSOR |
| Focal Distance | 20x optical zoom lens, f=6.7±5%~125±5%mm |
| Digital Zoom | 9x Digital Zoom |
| Low Illumination | 0.29 SNR1s(lx) |
| AF Time | Real-time fast focusing, focusing time < 1s |
| Видеовыход | IP network output supports 4K, 1080P, and local TF storage |
| Field Angle (FOV) | D: WIDE 66.6° ±5% TELE 4.0° ±5% H: WIDE 59.6° ±5% TELE 3.5° ±5% V: WIDE 35.7° ±5% TELE 2.0° ±5% |
| IP Output Mode | 4K 30fps |
| Режим управления | IP, Serial port |
| Размер карданного шарнира | 140mm×162mm×144mm |
| Рабочее состояние | -10°C to +50°C / 20% to 80% RH |
| Среда хранения | -20°C до +60°C / 20% до 95% RH |
| Main Applications | UAV aerial photography |
| Вес | 635±10g |
Capture stunning 4K footage with TOPOTEK’s KIP20S78 drone camera gimbal. Features include a 3-axis stabilized system, 20x optical zoom, and night vision capabilities for exceptional low-light performance. The gimbal also supports IP output, RTSP, and H.264/H.265 encoding. Additional features include a starlight sensor (1/1.8
