FLYWOO new top GOKU series AIO are finally here! GOKU GNF745 40A FC is currently the highest level of all-in-one FC, which can meet all your FPV needs.

Use powerful F745 BGA chip and BLHELI_32 ESC firmware, integrate 5V/9V dual BEC, barometer, black box, WS2812LED, support 7 complete hardware serial ports, I2C and other functions are all open.
This is currently the most integrated and powerful FC AIO board on the market. It brings pilots a more stable and smoother flight.! Perfect for ultralight quad! It will be the most powerful FC AIO board in 2021.

Main Changelog from V1 to V1.2 :

• Improve the land layout. Increase the pad spacing, easier to sol

• Upgrade to 1MB flash

Характеристики
F745 MCU

• Барометр

• Dual BEC 5V/9V

• Black Box

• 40A 32Bit ESC

• 7 UARTS

GN745 AIO Контроллер полета

• MCU: STM32F745 32-bit processor,216MHz, 1MB Flash

• IMU: MPU6000 (SPI)

• Barometer: BMP280

• Onboard LED：WS2812*4

• USB VCP Driver (all UARTs usable simultaneously; USB does not take up a UART)

• 7 hardware UARTS (UART1,2,3,4,5,6,7)

• Supports serial receivers (SBUS, iBus, Spektrum, Crossfire) only.

• PPM and PWM receivers are not supported.

• Onbord 8Mbytes for Blackbox logging

• 9V Power Out: 1.5A max

• 5V Power Out: 2.0A max

• 3.3V Power Out: 0.5A max

• Dimensions: 33.5×33.5mm

• Mounting Holes: Standard 25.5/26.5mm square to center of holes

• Вес: 8,5 г

Built-in 40A BL_32 4in1 ESC

• Support BLheli / BLHELI_32

• Support PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600,Dshot1200

• Входное напряжение: 2-6S Lipo

• Continuous Current: 40A

• Firmware: BLHELI_32

Q&A :
1、 Betaflight Firmware target: FLYWOOF745
2、INAV Firmware target: FLYWOOF745
3、GOKU GN 745 40A AIO BL_32 Wiring Diagram  🙁LINK)
