TOPOTEK KIP30S90 EO Gimbal Camera Specification
| المعلمة | المواصفات |
|---|---|
| الفولتية | 3S-6S (11V-24V) |
| الطاقة | Dynamic 10W |
| زاوية التدحرج | -85°~+85° |
| زاوية التدوير | -90°~+90° |
| زاوية الانعراج | 360° continuous rotation |
| Jitter Angle | ±0.02° |
| زاوية الاهتزاز الأفقي | ±0.03° |
| استعادة بنقرة واحدة | استعادة الوضع الأولي بنقرة واحدة |
| سرعة الدوران المحوري القابلة للتعديل | When the PTZ rotates, it conducts speed adaptation based on the current speed mode and the multiple of visible light camera. |
| وضع التحكم | Support network IP control and serial port control (SBUS and PWM control are optional) |
| حجم CMOS | 1/2.8 Inch 2 Mega Pixels Wide Dynamic CMOS SENSOR |
| Focal Distance | 30x optical zoom lens, f=4.5±10%~135±10%mm |
| Digital Zoom | تكبير/تصغير رقمي 9x |
| وقت التركيز التلقائي | Real-time fast focusing, focusing time < 1s |
| إخراج الفيديو | IP network output supports 4K, 1080P, and local TF storage |
| زاوية المجال (FOV) | D: WIDE 67.8° ±5% TELE 2.77° ±5% H: WIDE 59.8° ±5% TELE 2.34° ±5% V: WIDE 40.5° ±5% TELE 1.48° ±5% |
| IP Output Mode | 1080 بكسل 30 إطاراً في الثانية |
| Working Frequency | 806-826MHZ |
| Wireless Power and Transmission Distance | 25dBm 10KM |
| وضع التحكم | IP, Serial port, PC side app mouse, key operation |
| Gimbal Size | 140mm×160mm×143mm |
| حالة العمل | -10 درجات مئوية إلى +50 درجة مئوية / 20% إلى 80% رطوبة نسبية |
| بيئة التخزين | -20 درجة مئوية إلى +60 درجة مئوية / 20% إلى 95% رطوبة نسبية |
| Main Applications | التصوير الجوي بالطائرة بدون طيار |
| الوزن | 655±10g |
The KIP30S90 is a single EO gimbal payload integrated with a 30x optical zoom, 3-axis stabilized PTZ, and IP output. The ground receiving end IP outputs RTSP code streams, and the ground end software supports PTZ control and zoom camera control. The PTZ adopts a high-precision encoder FOC control scheme, offering high stability, small size, lightweight design, and low power consumption. The camera features a 2-megapixel wide dynamic CMOS sensor, supporting 1080P local TF storage and wireless transmission.
Advantages
- 30x Optical Zoom: Allows for detailed close-ups without losing image quality.
- Standard RTSP Stream Output: Ensures compatibility with various streaming applications.
- TF Card Storage: Facilitates convenient and expandable local storage.
- Follow / Lock Mode: Enhances tracking and focus capabilities.
- 170ms Low Latency: Provides near-instantaneous feedback and control.
- تكبير/تصغير رقمي 9x: Adds further flexibility in framing shots.
- Image and Data Use the Same IP: Simplifies network configuration and reduces the need for additional hardware.
- 3-Axis Stabilized Gimbal: Ensures smooth and stable footage, even in dynamic conditions.
- Lightweight at 655g: Easy to integrate into various platforms without adding significant weight.
Connection pin details: Power supply via 3S or 6S VIN (ground) with device structure dimensions: 16mm x 0.02mm x 143mm x 37mm x 40mm.
