SPECIFICATIONS
Wheelbase: Screws
Use: Vehicles & Remote Control Toys
Upgrade Parts/Accessories: Lithium Battery
Tool Supplies: Assembled class
Technical parameters: Value 3
Remote Control Peripherals/Devices: Motor
RC Parts & Accs: Motors
Quantity: 1 pcs
Origin: Mainland China
Model Number: SunnySky X3525
Material: Metal
Four-wheel Drive Attributes: Motors
For Vehicle Type: Airplanes
Brand Name: NoEnName_Null
X3525 Ⅲ:
Features:
1.N48UH Magnets, 0.2mm Air gap, Coil with high copper space factor, Ultimate power.
2.Original NSK bearing,Low noise and friction factor, more stable and smooth.
3.The new type of propeller base is designed with more stable performance andmore convenient disassembly.
4.Around the stator end cover is hollowed design, and the heat dissipation area is increased, so the heat dissipation is better.
5.Hidden motor shaft design is adopted to protect motor shaft more effectively.
Description:
1.This is a brushless motor for Fixed – Wing 3D RC drone parts accessories.
2.Anti-slip: Overlapping curve to increase friction force and prevent propellers from slipping.
3.Excellent workmanship quality guarantees power saving and high efficiency,bring you stimulated flight.
Specifications:
Brand name: SUNNYSKY
Model:X3525 Ⅲ
Item name: Brushless Motor
KV:465KV
Color:Blue
465KV
Stator Diameter:35mm
Stator thickness:25mm
NO. of Statpr Arms:12
NO. of Roter Poles:14
NO-Load Current:1.07A/10V
Moter Resistance:26mΩ
Max Continuous Current:84A/30s
Max Continuous Power:2100W
Rotor diameter:42.5mm
Length of motor (excluding shaft length):48mm
Shaft diameter:6mm
Motor Size:42.5mm/1.66in x 67mm/2.61in
Max Lipo Cell:6S
Recommended ESC:60-80A
Recommended Prop(inch):EOLO14*7 14*8 15*8 15*10
Weight:259g/pcs
